Raing 额定: 5A 125/250VAC (ENEC,CQC,CB)
12A 250VAC (ENEC,CQC,CB)
16A 250V (ENEC,CQC,CB)
5/80A 250VAC uT125 (ENEC,CQC,CB)
ELECTRICAL(电气特性):
(接触电阻) INITIAL CONTACT RESISTANCE: 30mΩ Max.
(操作力量) OPERATION FORCE: 500±200gf
(绝缘电阻) INSULATION RESISTANCE: 100MΩ Min. 500VDC
(电气寿命) ENDURANCE: 10,000 CYCLES
(耐 电 压) WITHSTAND VOLTAGE: 1 KVAC FOR 1MINUTE
MATERIAL (材质):
(基座) TERMINAL BASE: PHENOLIC(UL 94V-0)
(柄) ACTUATOR: PBT+30%G.F.(UL 94V-0)
(接触片) CONTACT: Ag Alloy
(弹簧) SPRING: STAINLESS STEEL WIRE
